SINOTRUK
HOWO 4×2 Concrete Mixer Truck
Driving Type
4×2
Mixer Tank Volume
4 m³
Application
Construction of roads, bridges, and high-rise buildings
- Mixer Truck
Product Description
Our service
PRODUCT FEATURE
High efficiency in concrete delivery and mixing.
Low operating costs due to energy-efficient designs.
Long lifespan with proper maintenance.
PARAMETERS
| Model | HOMAN 4×2 Mixer Truck | |
| Chassis Model | ZZ3158E3415C1R | |
| Drive type | 4×2 | |
| Kerb Weight(kg) | 5800 | |
| payload (kg) | 10000 | |
| Dimensions LxWxH(mm) | 9500×2500×3700 | |
| Wheelbase(mm) | 6800X2300X2300 mm | |
| Cabin | Model | 2080 |
| Engine | Model | YC4E160-33 |
| Horse Power(Hp) | 160 | |
| Rated power(kW/rpm) | 118kW/2600rpm | |
| Emission | Euro III | |
| Displacement | 4.26 | |
| Transmission | Model | 8JS85F |
| Gear position | 7 forwards &1 reverses | |
| AXLE | Front axle Load capacity(kg) | 3600 |
| rear axle Load capacity(kg) | 10000 | |
| Ratio | 6.33 | |
| Chassis | Thinkness(mm) | 9/11+8 |
| Leaf spring | Type | 280×（8+5） |
| Tire | Mode | 10.00R20 |
| Barrel | Tank size(mm) | 4 m³ |
| Dished End | Q345 6mm | |
| Front Cone | Q345 5mm | |
| Mid section | Q345 5mm | |
| Rear Cone | Q345 5mm | |
| Blade | Q345 4mm | |
| Hydraulic | Motor | Eaton |
| Pump | Eaton | |
| Gearbox | PMB/ZF | |
| Water system | ater tank Volume | 300 L |
| System | Pressurized water supply system | |
| Working Pressure | 2 Bar | |
- Mixer Truck
Product Detilas
