SINOTRUK
HOMAN 4X2 Dump Truck
Driving Type
4×2
Box Body(mm)
4200*2300*1500
Application
lighter-duty construction cargo transportation
- Dump Truck
Product Description
Our service
PRODUCT FEATURE
HOMAN 4×2 Dump Truck is a light-to-medium duty truck for transporting loose materials like sand, gravel, and debris in construction and urban settings. It’s a practical choice for urban construction, landscaping, and light industrial work, balancing durability, efficiency, and ease of use for operators in lighter-duty applications.
PARAMETERS
| Model | HOWO-7 4×2 DUMP Truck | |
| Chassis Model | ZZ3158E3415C1R | |
| Drive type | 4×2 | |
| Kerb Weight(kg) | 6880 | |
| payload (kg) | 10000 | |
| Dimensions LxWxH(mm) | 6450×2420×2880 | |
| Wheelbase(mm) | 3650 | |
| Cabin | Model | 2080 |
| Engine | Model | YC4E160-33 |
| Horse Power(Hp) | 160 | |
| Rated power(kW/rpm) | 118kW/2600rpm | |
| Emission | Euro III | |
| Displacement | 4.26 | |
| Transmission | Model | 8JS85F |
| Gear position | 7 forwards &1 reverses | |
| AXLE | Front axle Load capacity(kg) | 3600 |
| rear axle Load capacity(kg) | 10000 | |
| Ratio | 6.33 | |
| Chassis | Thinkness(mm) | 9/11+8 |
| Suspension | Type | 280×（8+5） |
| Tire | Mode | 10.00R20 |
| Superstructure | body size(mm) | 4200×2300×1500 |
| Thinkness(mm) | bottom 4 ,side 3 | |
| Lift type | Milddle , T type | |
- Dump Truck
Product Detilas
