HOWIN
40Ft 3Axles Skeletaon Semi-Trailer
Axle Quantity
3 Axles
Payload(kg)
45,000
Suspension Type
Mechanical Suspension
- Skeleton semi-trailer
Product Description
Our service
VEHICLE CONFIGURATION
| Overall Dimension | 12500×2500×1600(mm) |
| Tare weight | 6500 （kg） |
| Pay Load | 40,000 kg |
| Wheel base | 7500+1350+1350 mm |
| Chassis
|
Material:Q345 |
| Upper flange: 14 mm | |
| bottom flange: 16 mm | |
| middle flange ：8 mm | |
| Axle | BPW / FUWA 13 ton |
| Suspension | Germany style mechanical suspension |
| Brake system | Dual line braking system Wabco brand relay valve and ABS |
| Container lock | 12 units |
| King Pin | 50# inch or 90# inch |
| Landing Gear | Jost brand 28 tons |
| Tyre | 12R22.5, 315/80R22.5, 385/60R22.5 |
| Fuel tank | 1000 L |
| Painting | Frame sandblasting, polyurethane primer, polyurethane top coat |
| Others | 30L water tank, side bumper， two spare tire racks |
- Skeleton semi-trailer
Product Detilas
